Mirka Power Lead – Correct Use and Handling Instructions

The Mirka power lead is designed with a safety release mechanism that must be used correctly when connecting and disconnecting the lead from the sander. Failure to follow the correct procedure can result in damage to both the power lead and the sander itself.

Incorrect Use

Incorrect handling occurs when the power lead is removed by force without first depressing the release tab located on the underside of the connector.

In the image provided, the highlighted area shows damage caused by forcibly pulling the power lead out of the sander without using the release tab. This action has:

• Broken the release tab on the sander

• Damaged the power lead connector

• Caused internal electrical damage to the sander

As a result of this incorrect use, the sander requires:

• Replacement of the PCB electrical power board

• Replacement of the power lead

This type of damage is not caused by a product fault, but by improper disconnection.

Identifying Damage

The images also compare:

1. A damaged power lead, which shows a rounded and worn connector profile caused by forced removal

2. A correctly maintained power lead, which retains a clean, defined connector shape

3. The lead release tab, which must be intact and functional to ensure safe connection and disconnection

A damaged lead may no longer lock correctly into the sander and can lead to intermittent power issues or further damage if continued use occurs.

Correct Use

In the image provided, the highlighted area shows no damage when the Mirka power lead is connected and disconnected correctly.

Correct Use Instructions

To safely disconnect the Mirka power lead:

1. Locate the release tab on the underside of the power lead connector

2. Firmly depress the release tab

3. While holding the tab down, gently pull the power lead straight out of the sander

Never pull or twist the power lead without first engaging the release mechanism.

Important Note

Always inspect the power lead and connector before use. If damage is visible, discontinue use immediately and replace the affected components to prevent further damage or safety risks.
